BLOW MOULDING PROCESS:

MACHINE ADVANTAGES
1.Energy saving over 50%, benefit from minimized preform heating pitch.
2. Structures with optimized design enable a higher per cavity output of 1,800-2,000bph.
3. Comparing with standard ordinary machine, few air cylinders in use, less maintenance cost.
4. Equipped with servo motors, faster action and no separate low pressure air input is required for operation.
KEY FEATURES
1. Preform Feeding
1)Rotary dial plate design enablecontinuousand high speed preformfeeding;
2)No pneumatic claws, more reliable and less maintenance;
3)Multiple protection device for precise preform feeding.
2. Transfer and heating
1)Horizontal rotation transfer style, no preform turnover, simple structure;
2)Minimized preform heating pitch for less energy consumption;
3)Cooling channel applied in neck area to guarantee no deform of preform neck;
4)Optimized ventilation to ensure heating consistency;
5)Equipped with function of preform temperature detection.
3. Transfer and bottle out
1)Servo motor driving for preform transfer and location with quick and precise action;
2)No pneumatic clampers were used for bottle taking out, less maintenance in future, less running cost.
4. Clamping and stretching blow molding
1)Servo motor clamping system with synchronized base blow mold for fast response operation;
2)Precision electromagnetic blowing valve group for fast and high productivity;
3)No link rod,no toggle structure, simple and reliable clamping system. Less maintenance required.
5. Controlling
Siemens controlling system with 9 inch touch screen for simple and stable operation.
6. Others
1)Simplified construction, quick mold changedesign;
2)Low power and air consumption, longer life-span and lower wear, more clean structure.
3)Be able to be connected directly to air conveyor to bottling production line easily.
MACHINE DETAILS
PET preform continuous feeding
Design: Patent preform holder, motor feeding, with protect device, no pneumatic parts,
Advantage: Fast and stable


Power Saving Heating System
Design: Minimized heating pitch
Advantage: Energy saving over 50%
High Pressure Blowing Valve group
Brand: SEITZ, Switzerland
Functions including:
1. Pre-blow
2. High pressure blowing
3. Blowing exhaust
4. Blow air recycle (optional)


Stretching
Design: by Servi motor
Advantage: Fast and precision
MACHINE DETAILS
Mold Clamping
Design: Cam linkage structure, servo motor, standard sizes.
Advantage: Fast clamping, quick mold changing.


After blowing bottle directly connect to filling line
Design: a section with air blowing for air conveyor
Advantage: connect to air conveyor line directly, or directly transfer to rinsing section of filling machine synchronously similar to combi machine.
Motion PLC Siemens
Design: Siemens motion PLC, servo motor system, heating by intelligent regulators
Advantage: Fast and synchronous actions, precision controlling.

TECHNICAL PARAMETERS
Model | CP5-2.5L | CP6-1.5L | CP7-1.5L | CP8-1.0L | CP9-0.7L | ||
Theoretical production capacity(1) | BPH | 10000 | 12000 | 14000 | 16000 | 18000 | |
Number of mold cavity | PC | 5 | 6 | 7 | 8 | 9 | |
Container | Max.bottle volume | L | 2.5 | 1.5 | 1.5 | 1.0 | 0.7 |
Max. neck diameter | mm | 30 | 30 | 30 | 30 | 30 | |
Max.bottle diameter | mm | 110 | 95 | 95 | 80 | 70 | |
Max. bottle height | mm | 350 | 350 | 350 | 300 | 300 | |
Molding | Spindle pitch (Heating pitch) | mm | 38 | 38 | 38 | 38 | 38 |
Cavity pitch | mm | 125 | 105 | 105 | 90 | 80 | |
Power | Max.heating power | KW | 50 | 40 | 80 | 80 | 60 |
Servo motor power | KW | 16.5 | 16.5 | 16.5 | 16.5 | 16.5 | |
Other motor power | KW | 4.2 | 4.2 | 5 | 5 | 5 | |
Total power | KW | 70.7 | 60.7 | 102 | 102 | 82 | |
Voltage/Frequency | V/HZ | 380/220V±10% 50/60HZ | |||||
Air system | Operating pressure | bar | 7 | 7 | 7 | 7 | 7 |
Air consuming | L/min | 1000 | 1000 | 1000 | 1000 | 1000 | |
Blowing pressure | bar | 35 | 35 | 35 | 35 | 35 | |
High pressure air consuming(2) | L/min | 5000 | 6500 | 7500 | 8000 | 9000 | |
Mold cooling water | Operating pressure | Bar | 3-5 | 3-5 | 3-5 | 3-5 | 3-5 |
Temperature range | ℃ | 10-12 | 10-12 | 10-12 | 10-12 | 10-12 | |
Flow rate | L/min | 50 | 50 | 50 | 50 | 50 | |
Cooling capacity | HP | 5 | 5 | 5 | 5 | 5 | |
Heater cooling water | Operating pressure | bar | 3-5 | 3-5 | 3-5 | 3-5 | 3-5 |
Temperature range | ℃ | 15-20 | 15-20 | 15-20 | 15-20 | 15-20 | |
Cooling capacity | HP | 5 | 5 | 5 | 5 | 5 | |
Machine | Measurement(LxWxH) | m | 5.2*1.5*2.6 | 5.2*1.5*2.6 | 5.8*1.5*2.6 | 5.8*1.5*2.6 | 5.8*1.5*2.6 |
Weight | KG | 5500 | 5500 | 6000 | 6000 | 6000 |
1. The theoretical production capacity and the actual power consumption depend on bottle size, shape and bottle weight.
2. High pressure consuming depends on bottle size and operating conditions.
3. Specifications might be changed when the machine is improved without prior notice.
